120W output stage with cathodyne phase inverter and filtered presence control


This British design dared to be different from contemporaries. Quite different tone stack, selectable capacitor filter, a resonant presence control. The power amp is similar to that from a 50s US design but with negative feedback (and that presence control) for better control.
