Bass amp with 300W output stage, cathodyne phase inverter followed by pentode gate driver stages


A 300W bass head that uses a lot of valves. Six 6550 power pentodes needs two cathode followers just to drive the gates; four more triodes add gain before and after the cathodyne phase splitter. There's seven more triodes in a complex pre-amp letting you sculp your bass tone just so.

Click to enlarge
